DEEPCOOL CASTLE 360 RGB V2 ARGB AIO LIQUID COOLER
From the manufacturer
CASTLE 360 RGB V2 is equipped with Anti-Leak Tech. It has built-in double window panes. 16.7M true color lighting system provides a perfect display of aesthetic illumination. Its ultra-large, pure copper CPU block and its optimized E-shaped micro water channel are designed to enlarge heat contact areas and effectively enhance heat circulation efficiency to meet the user’s needs for high performance and aesthetics.
Supports mainstream INTEL and AMD socket mounting, including TR4/AM4.
Fabulous Aesthetics Inherited
The 16.7M true color RGB flowing light system with 5 in-built effects (dynamic, static, breathing, comet, and fashion collision) has 36 interchangeable lighting modes and also supports motherboards with synchronized lighting control via an addressable RGB function.
- LED Type: Addressable RGB LED
- LED Rated Voltage: 5VDC
- LED Connector: 3pin(+5V-D-G)
- LED Control: M/B with 5V ADD-RGB Header
- Radiator Dimensions: 402×120×27mm (L×W×H)
- Radiator Material: Aluminum
- Net Weight: 1768g
RGB Control Methods
- The synchronized RGB lighting of the waterblock and fans is easily controlled with the included wired controller.
- Motherboards are also supported with synchronized lighting control via addressable RGB function.
The latest 120mm RGB case fans provide a flowing lighting effect, designed for builders with addressable RGB-enabled PCs to match their system’s style perfectly.
The optimized E-shaped micro water channel design effectively enhances heat circulation efficiency and enlarges heat contact areas.
Ultra-large, pure copper CPU block provides effective coverage and heat dissipation for CPUs of any size, including TR4/AM4.
|Pump Dimensions||91×79×71 mm|
|Radiator Dimensions||402×120×27 mm|
|Net Weight||1768 g|
|Tube length||465 mm|
|Pump Speed||2550 RPM±10%|
|Pump Noise||17.8 dB(A)|
|Pump Rated Voltage||12 VDC|
|Pump Rated Current||0.21 A|
|Pump Power Consumption||2.52 W|
|Fan Dimensions||120×120×25 mm|
|Fan Speed||500~1800 RPM±10%|
|Fan Airflow||69.34 CFM|
|Fan Air Pressure||2.42 mmAq|
|Fan Noise||≤30 dB(A)|
|Fan Connector||4-pin PWM|
|Bearing Type||Hydro Bearing|
|Fan Rated Voltage||12 VDC|
|Fan Rated Current||0.17 A|
|Fan Power Consumption||2.04 W|
|LED Type||Addressable RGB LED|
|LED Rated Voltage||5 VDC|
|LED Power Consumption||2.25 W（PUMP）/ 7.2 W（FAN×3）|
