56% OFF
Gigabyte H610M S2 DDR4 Motherboard
Gigabyte H610M S2 DDR4 Motherboard - Image 2
Gigabyte H610M S2 DDR4 Motherboard - Image 3

Gigabyte H610M S2 DDR4 Motherboard

Price:

Original price was: ₹14,800.00.Current price is: ₹6,499.00.

Out of stock

Why shop from Mostech Computers?

PAN India Superfast Delivery

Get your order delivered to your doorstep at the earliest.

Best Prices & Offers

Get Best Price and Deals at Mostech Computers.

Trusted Seller

Mostech is one of the Most Trusted Seller in India.

Product Description

Specification:

CPU
  • LGA1700 socket: Support for 12th Generation Intel® Coreâ„¢, Pentium® Gold and Celeron® Processors
  • L3 cache varies with CPU
Chipset Intel® H610 Express Chipset
Memory
  • Support for DDR4 3200/3000/2933/2666/2400/2133 MHz memory modules
  • 2 x DDR4 DIMM sockets supporting up to 64 GB (32 GB single DIMM capacity) of system memory
  • Dual channel memory architecture
  • Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
  • Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
  • Support for Extreme Memory Profile (XMP) memory modules
Onboard Graphics 1 x D-Sub port, supporting a maximum resolution of 1920×1200@60 Hz
Audio
  • Realtek® Audio CODEC
  • High Definition Audio
  • 2/4/5.1/7.1-channel
LAN Realtek® GbE LAN chip (1 Gbps/100 Mbps)
Expansion Slots
  • 1 x PCI Express x16 slot, running at x16
    (The PCI Express x16 slot conforms to PCI Express 4.0 standard.)
  • 1 x PCI Express x1 slot
    (The PCI Express x1 slot conforms to PCI Express 3.0 standard.)
Storage Interface
  • 1 x M.2 connector (Socket 3, M key, type 2260/2280 PCIe 3.0 x4/x2 SSD support)
  • 4 x SATA 6Gb/s connectors
USB
  • 4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header)
  • 4 x USB 2.0/1.1 ports on the back panel
  • 4 x USB 2.0/1.1 ports available through the internal USB headers
Internal I/O Connectors
  • 1 x 24-pin ATX main power connector
  • 1 x 8-pin ATX 12V power connector
  • 1 x M.2 Socket 3 connector
  • 4 x SATA 6Gb/s connectors
  • 1 x CPU fan header
  • 2 x system fan headers
  • 1 x RGB LED strip header
  • 1 x front panel header
  • 1 x front panel audio header
  • 1 x USB 3.2 Gen 1 header
  • 2 x USB 2.0/1.1 headers
  • 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
  • 1 x serial port header
  • 1 x Clear CMOS jumper
Back Panel Connectors
  • 1 x PS/2 keyboard port
  • 1 x PS/2 mouse port
  • 1 x D-Sub port
  • 2 x USB 3.2 Gen 1 ports
  • 4 x USB 2.0/1.1 ports
  • 1 x RJ-45 port
  • 3 x audio jacks
I/O Controller iTE® I/O Controller Chip
H/W Monitoring
  • Voltage detection
  • Temperature detection
  • Fan speed detection
  • Overheating warning
  • Fan fail warning
  • Fan speed control
BIOS
  • 1 x 256 Mbit flash
  • Use of licensed AMI UEFI BIOS
  • PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Unique Features
  • Support for APP Center
  • Support for Q-Flash
  • Support for Xpress Install
Bundled Software
  • Norton® Internet Security (OEM version)
  • LAN bandwidth management software
Operating System
  • Support for Windows 11 64-bit
  • Support for Windows 10 64-bit
Form Factor Micro ATX Form Factor; 23.0cm x 21.5cm
Warranty 3 Years
Note *** Features, Price, Specifications are subject to change without notice.
Brand

Gigabyte
Platform

Intel
Socket

LGA1700
Chipset

H610
Supported Memory Type

DDR4
Maximum Memory Support

32 GB
Form Factor

M-ATX
SKU: H610M-S2-DDR4 Categories: , , Tags: , , , , ,

Related products

Related products

Recently viewed by you

Adata XPG Lancer RGB Series 16GB DDR5 6000MHz RAM

Adata XPG Lancer RGB Series 16GB (16GBx1) DDR5 6000MHz Desktop RAM

Original price was: ₹16,000.00.Current price is: ₹5,199.00.

Gigabyte RTX 4070 Ti Super Aero OC 16GB Graphics Card

Gigabyte RTX 4070 Ti Super Aero OC 16GB Graphics Card

Original price was: ₹310,000.00.Current price is: ₹82,799.00.

ADATA XPG Lancer RGB 32GB (16GBx2) DDR5 7200MHz Desktop Ram

ADATA XPG Lancer RGB 32GB (16GBx2) DDR5 7200MHz Desktop Ram

Original price was: ₹26,999.00.Current price is: ₹13,620.00.

Adata 16GB (16GBx1) DDR5 5600MHz Laptop Ram
